Frame
Carbon with DT storage, UDH compatible
Fork
Carbon, 51mm offset, 12x100mm TA
Rear shifter
Shimano GRX ST610, 12sp
Rear derailleur
Shimano GRX RD-RX822, 10-45T, 12sp, GS
Front shifter
Shimano GRX ST610, 1x
Crankset
Shimano GRX FC-RX610 40T, 47CL, 165mm (S1,S2) - 170mm (S3,S4) - 172.5mm (S5)
Bottom bracket
Shimano BSA 68mm
Cassette
Shimano CS-M7100, 10-45T, 12sp
Chain
KMC X12
Front brake
Shimano BR-RX400, resin w/o fin
Front brake rotor
Shimano SM-RT64, 160mm, c-lock
Rear brake
Shimano BR-RX400, resin w/o fin
Rear brake rotor
Shimano SM-RT64, 160mm, c-lock
Brake levers
Shimano GRX ST610
Handlebar
Norco Super Flare Aluminum Compact, 40cm (S1,S2) - 42cm (S3) - 44cm (S4) - 46cm (S5), 16 degree
Stem
Norco SL Alloy 70mm length, 31.8mm clamp
Seatpost
Norco Alloy, 27.2mm, 0deg offset, 350mm length
Headset
FSA Integrated Sealed Bearings No. 42, tapered 1-1/8" - 1.5" (IS42/28.6 | IS52/40)
Saddle
Selle Royale SRX Gravel, 148mm
Grips
Griptacular Shockproof Tape 3mm
Seatpost clamp
Norco Aluminum, 31.8mm ID
Front hub
Shimano HB-TC500 Sealed Bearing, 12x100mm, 28H, C-lock
Rear hub
Shimano FH-TC500 Sealed Bearing, 12x142mm, Micro Spline, 28H, C-lock
Rims
WTB ST i25 2.0, 28h, 25mm ID
Front tire
Schwalbe G-One All Round, Race Guard, 700x45c
Rear tire
Schwalbe G-One All Round, Race Guard, 700x45c
Spokes/nipples
Double butted, black alloy
Valves
WTB TCS Tubeless Valve, brass
Sealant
WTB TCS Tubeless Tire Sealant, 8oz/236ml
Rim tape
WTB TCS 2.0 Solid Strip
Weight
9.5 kg (20.9 lbs)
Weight size
S3
Accessories
Norco Storage Bag - Ocean-X Water Resistant
Tire clearance
Up to 50c
